FTS Ball Valve
Female X Female X Female
2-way on-off Switching Models.
Heavy directional handle or lever handle.
Blow-out proof bottom loaded stem. Low operating torque and with panel mounting facilities.
Series of end connections 1/4" to 1" NPT, BSP, BSPT. Male or female threaded ends and 1/4", 3/8" and 1/2" "FTS" single or twin ferrule tube fitting ends.
Floating Ball design for positive sealing.
Maximum Working Pressure: 6000 PSI (400 bar) at 20°C to 250°C with TFE Seat.
High Pressure Ball Valve with 10,000 PSI (700 Bar) are available with polyamine or KEF-F seats, for high pressure diversion. Very robust and easy to maintain.
