FTS Check Valve

Female X Female

Features:

  • Available in High Grade Stainless Steel, Bass materials

  • Variety of end connections includes Male / Female threaded NPT, BSP, BSPT, ISO, DIN and JIS tapered pipe ends.

  • 100% factory tested for both crack & reseal

  • Complete Heat Traceability

Orifice:

  • 1.078" to 0.656" (2.0 mm to 16.7 mm)

CY Factor:

  • 0.18 to 6.56

Pressure / Temperature Ratings:

Pressure Rating

  • 316SS - 1/8" to 3/4"- 5000 PSIG CWP (345 bar)

  • 1" - 3000 PSIG CWP (207 bar)

  • Brass - 1/8" to 1" - 3000 PSIG CWP (207 bar)

Working Temperatures

  • Viton seal -15° F to 375° F (-26°C to 190°C)

  • Fluorocarbon Rubber -15° F to 400° F (-26°C to 204°C)

  • Buna - N Rubbed -30° F to 275° F (-34°C to 135°C)

  • Neoprene Rubber -45° F to 250° F (-43°C to 121°C)
